Samsung patents method to queue emergency alerts when cell capacity is full
This filing describes a way for cell towers to handle multiple emergency warnings sent at the same time. If the broadcast slots are already taken by a first alert, the system saves the second alert in a temporary buffer and sends it immediately after the first one finishes.
In the filing’s own words
An electronic device is provided. The electronic device includes memory that stores instructions, and at least one processor. The instructions, when executed by the at least one processor individually or collectively, cause the electronic device to receive a first request message for broadcasting a first warning message of system information (SI) for a public warning system (PWS), in response to the first request message, transmit first segments of the first warning message on a cell during a first transmission period corresponding to two modification periods, based on receiving a second request message for broadcasting a second warning message of the SI in the first transmission period, determine whether all available SI windows are in use or not, in a case that all the available SI windows are in use, store the second warning message in a buffer, and after all the first segments of the first warning message are transmitted, transmit second segments of the second warning message on the cell during a second transmission period corresponding to the two modification periods.
What exactly they claim (claim 1)
1. An electronic device comprising: memory storing instructions; and at least one processor, wherein the instructions, when executed by the at least one processor individually or collectively, cause the electronic device to: receive a first request message for broadcast of a first warning message of system information (SI) for a public warning system (PWS), transmit first segments of the first warning message on a cell during a first transmission period corresponding to two modification periods, in response to the first request message, based on receiving a second request message for broadcast of a second warning message of the SI in the first transmission period, determine whether all of available SI windows are in use or not, in a case that all of the available SI windows are in use, store the second warning message in a buffer, and after all of the first segments of the first warning message are transmitted, transmit second segments of the second warning message on the cell during a second transmission period corresponding to the two modification periods.
Facts
- Company
- Samsung (Samsung Electronics Co., Ltd.)
- Official title
- ELECTRONIC DEVICE AND METHOD FOR TRANSMITTING WARNING MESSAGE IN WIRELESS COMMUNICATION SYSTEM
- Publication number
- US20260323264A1
- Application number
- 19690804
- Filed
- May 28, 2026
- Published
- Oct 15, 2026
- Inventors
- 4
- Claims
- 20
Classified under
H04W 4/90 Electricity & electronicsH04W 4/12 Electricity & electronicsH04W 68/02 Electricity & electronicsMore from Samsung in Networks & wireless
