Samsung patents 5G/6G data routing method for network efficiency
Samsung describes a method for 5G or 6G networks where a specific part of data is handled by a separate 'data proxy' entity. Instead of sending the full message, the network function sends a partial message to this proxy, which processes the missing data and forwards it to the destination.
In the filing’s own words
The present disclosure relates to a 5G or 6G communication system for supporting higher data transmission rates. In addition, the present disclosure relates to a method performed by a first network function (NF), and an apparatus for performing same, the method including the steps of: determining a data proxy (DP) entity for a service with a second NF; generating a service message that does not include a part of data for the service; and transmitting the service message to the DP entity, wherein the part of data for the service is processed by the DP entity and is transmitted to the second NF.
What exactly they claim (claim 1)
1. A method performed by a first network function (NF), the method comprising: determining a data proxy (DP) entity for a service with a second NF; generating a service message not including a part of data for the service; and transmitting the service message to the DP entity, wherein the part of data for the service is processed by the DP entity and is transferred to the second NF.
Facts
- Company
- Samsung (SAMSUNG ELECTRONICS CO., LTD.)
- Official title
- DATA MANAGEMENT FUNCTION AND METHOD FOR OPERATION OF NETWORK FUNCTIONS
- Publication number
- US20260322893A1
- Application number
- 19116789
- Filed
- Dec 23, 2022
- Published
- Oct 15, 2026
- Inventors
- 5
- Claims
- 15
Classified under
H04L 67/563 Electricity & electronicsH04L 67/51 Electricity & electronicsMore from Samsung in Networks & wireless
- Samsung patents UWB method to save power while tracking distance Sep 1, 2026
- Samsung patents system to keep satellite calls connected as satellites move Sep 1, 2026
- Samsung patents low-power IoT tags that reply without precise clocks Sep 1, 2026
- Samsung patents phone feature that switches networks to fix slow connections Sep 1, 2026
- Samsung patents satellite phone method for switching between signal types Sep 1, 2026
Summaries are simplified from the filing’s own abstract and first claim. A patent filing is not a product announcement.
