Samsung patents phone design that stacks charging coil and wires

Patent drawing
Patent drawing from the official filing.

Samsung describes a layout for electronic devices where a flexible circuit board sits directly on top of a wireless charging coil. To prevent the wires from interfering with the charging signal, a thin shielding layer is placed between the two components.

Why it mattersThis internal design tweak helps engineers fit charging hardware into thinner devices without signal interference.

In the filing’s own words

A wirelessly chargeable electronic device according to various embodiments may comprise: a first circuit board; a second circuit board; a battery; a flexible printed circuit board (FPCB) electrically connecting the first circuit board and the second circuit board to each other; and a wireless charging antenna stacked on the FPBC, wherein at least a part of the FPBC is arranged overlap in the width range of a pattern of the wireless charging antenna.

What exactly they claim (claim 1)

1. An electronic device capable of wireless charging, comprising: a first circuit board; a second circuit board; a battery; a flexible printed circuit board (FPCB) configured to electrically connect the first circuit board and the second circuit board to each other; a wireless charging antenna; and a shielding member comprising an electromagnetic shielding material, wherein the wireless charging antenna, the shielding member, and the FPCB are vertically stacked on different layers such that the shielding member is interposed between the wireless charging antenna and the FPCB, wherein at least a part of the FPCB is arranged to at least partially overlap a width range of a conductive pattern of the wireless charging antenna, and wherein at least one conductor of the FPCB extends in a direction parallel to and/or perpendicular to the conductive pattern of the wireless charging antenna.

Facts

Company
Samsung (SAMSUNG ELECTRONICS CO., LTD.)
Official title
Electronic device having wireless charging function
Patent number
US12763603B2
Application number
18103837
Filed
Jan 31, 2023
Granted
Oct 13, 2026
Inventors
8
Claims
15

Classified under

H02J 50/005 Electricity & electronicsH04B 5/24 Electricity & electronicsH04B 5/79 Electricity & electronicsH05K 1/0393 Electricity & electronicsH02J 2207/10 Electricity & electronics
