Google patents radar that learns new hand gestures automatically
This filing describes a system where a device uses radar to detect hand movements that it does not currently recognize. If the user issues a command near the time of the movement, the device saves the radar data for that specific motion as a new gesture. This allows the system to learn new controls over time without the user needing to go through a separate setup process.
In the filing’s own words
Techniques, apparatuses, and systems for in-line learning of new gestures for radar-enabled computing devices are described in this document. A computing system may store radar-signal characteristics of a new gesture to enable the computing system to recognize a new gesture and perform a command associated with the new gesture. Specifically, a radar system may detect a gesture performed by a user and fail to correlate that gesture to one or more known gestures. The computing system may receive a new command proximate to detecting the gesture and determine that the detected gesture is a new gesture associated with the new command. As such, the computing system may store a radar-signal characteristic of the new gesture effective to recognize a performance of the gesture in the future and respond by performing the command. In doing so, the computing system may periodically learn new gestures without requiring dedicated training from the user.
What exactly they claim (claim 1)
1. A method comprising: detecting, using a radar system associated with a computing device, a gesture performed by a user, the gesture associated with a radar-signal characteristic; comparing the radar-signal characteristic associated with the gesture performed by the user to one or more stored radar-signal characteristics, the comparing effective to determine a lack of correlation to one or more known gestures with which the one or more stored radar-signal characteristics are associated, the one or more known gestures associated with one or more known commands; receiving, proximate with detecting the gesture, a new command; responsive to the comparing effective to determine the lack of correlation and the receiving the new command, determining that the gesture is a new gesture associated with the new command; and storing the associated radar-signal characteristic to enable recognition of the new gesture at a future time effective to cause performance of the new command.
Facts
- Company
- Google (Google LLC)
- Official title
- In-Line Learning of New Gestures for Radar-Enabled Computing Devices
- Publication number
- US20260329386A1
- Application number
- 19113156
- Filed
- Sep 30, 2022
- Published
- Oct 22, 2026
- Inventors
- 6
- Claims
- 20
Classified under
