Samsung patents 5G method to fix errors in split AI processing
Samsung has filed a patent for a method that helps 5G or 6G networks handle errors when a neural network is split between a phone and a server. The phone sends partial results with error-checking codes, and if the server finds a mistake, it uses a backup part of the network to correct the data before finishing the calculation.
In the filing’s own words
The present disclosure relates to a 5G or 6G communication system to support higher data transmission rates. A server, in a communication system, may be configured to: receive, from a user equipment, intermediate data including result values obtained by processing at least one first layer from among a plurality of layers constituting a neural network and error detection codes for the result values; check whether there is an error in the intermediate data on the basis of the error detection codes; when an error is detected in the intermediate data, process the result values of the intermediate data by means of a second layer trained to correspond to the first layer; and derive a final result by processing an output of the second layer by means of at least one third layer subsequent to the first layer from among the plurality of layers.
What exactly they claim (claim 1)
1. A method performed by a user equipment (UE) in a communication system, the method comprising: obtaining configuration information for a transmission mode of intermediate data by split processing of a neural network; generating result values through processing of at least one first layer among a plurality of layers forming the neural network; generating the intermediate data by attaching error detection codes for the result values to the result values, based on the configuration information; and transmitting, to a server, the generated intermediate data including at least one subsequent second layer among the plurality of layers.
Facts
- Company
- Samsung (SAMSUNG ELECTRONICS CO., LTD.)
- Official title
- METHOD AND APPARATUS FOR RESPONDING TO TRANSMISSION ERROR IN SPLIT PROCESSING
- Publication number
- US20260323317A1
- Application number
- 19483963
- Filed
- Apr 3, 2024
- Published
- Oct 15, 2026
- Inventors
- 2
- Claims
- 14
Classified under
H04W 24/02 Electricity & electronicsH04L 1/0061 Electricity & electronicsH04L 41/16 Electricity & electronicsH04W 28/06 Electricity & electronicsMore from Samsung in AI & software
