Samsung patents live translation overlay for VoIP calls
Samsung describes a method for electronic devices to translate voice during internet-based calls. The system converts spoken words into text in the original language and then translates that text into a second language. Both versions are displayed together on the screen while the call is active.
In the filing’s own words
A method performed by an electronic device is provided. The method includes an operation of identifying that a call connection with an external electronic device is established through an application related to a voice over Internet protocol (VoIP), while the call connection is established, obtaining first voice data of a first language type, the first voice data being related to the application, obtaining a second text of a second language type distinguished from the first language type on the basis of a first text of the first language type converted from the first voice data of the first language type, displaying, through a display of the electronic device, a visual object including the first text and the second text, in an overlapping manner on a user interface for the application.
What exactly they claim (claim 1)
1. An electronic device comprising: a display; a speaker; a microphone; a communication circuit; memory, comprising one or more storage media, storing instructions; and at least one processor, comprising processing circuitry, wherein the instructions, when executed by the at least one processor individually or collectively, cause the electronic device to: identify that a call connection with an external electronic device through an application related to a voice over internet protocol (VoIP) is established, while the call connection is established, obtain first voice data of a first language type, related to the application, obtain, based on first text of the first language type converted from the first voice data of the first language type, second text of a second language type distinct from the first language type, and display, through the display, a visual object comprising the first text and the second text superimposed on a user interface for the application.
Facts
- Company
- Samsung (Samsung Electronics Co., Ltd.)
- Official title
- ELECTRONIC DEVICE, METHOD, AND NON-TRANSITORY COMPUTER-READABLE STORAGE MEDIUM FOR CONVERTING VOICE DATA RELATED TO APPLICATION
- Publication number
- US20260321261A1
- Application number
- 19712606
- Filed
- Jun 18, 2026
- Published
- Oct 15, 2026
- Inventors
- 7
- Claims
- 20
Classified under
G10L 15/22 Physics & computingG06F 40/58 Physics & computingH04M 3/5191 Electricity & electronicsMore from Samsung in AI & software
