Samsung patents wristwatch that changes shape based on your activity
This filing describes a wearable device with a flexible display and housing that can physically bend or unfold. It uses sensors to detect how the device is worn and what kind of activity you are doing, then automatically adjusts its shape to fit better.
In the filing’s own words
A wearable electronic device is provided. The wearable electronic device includes a housing including a first housing structure, a second housing structure connected to the first housing structure, and a third housing structure, a first hinge driving module configured to connect a first side of the first housing structure and the second housing structure such that the first housing structure and the second housing structure are folded and unfolded, a second hinge driving module configured to connect a second side of the first housing structure and the third housing structure such that the first housing structure and the third housing structure are folded and unfolded, a hinge driving unit configured to drive the first hinge driving module and the second hinge driving module, a display arranged in the housing, a sensor module configured to sense an angle between housing structures and to sense a bending curvature of the display, memory including at least one storage media, storing instructions, and at least one processor, including a processing circuit, communicatively coupled to the memory, wherein, the instructions, when executed by the at least one processor individually or collectively, cause the wearable electronic device to detect a state in which the wearable electronic device is worn on a wrist of a user using the sensor module, identify an activity state of the user using the sensor module based on detecting the state in which the wearable electronic device is worn on the wrist of the user, and adjust at least one of the angle between the housing structures and the bending curvature of the display based on a change in the activity state of the user.
What exactly they claim (claim 1)
1. A wearable electronic device comprising: a housing including a first housing structure, a second housing structure connected to the first housing structure, and a third housing structure; a first hinge driving module configured to connect a first side of the first housing structure and the second housing structure such that the first housing structure and the second housing structure are folded and unfolded; a second hinge driving module configured to connect a second side of the first housing structure and the third housing structure such that the first housing structure and the third housing structure are folded and unfolded; a hinge driving unit configured to drive the first hinge driving module and the second hinge driving module; a display arranged in the housing; a sensor module configured to sense an angle between housing structures and to sense a bending curvature of the display; memory, comprising at least one storage media, storing instructions; and at least one processor, including a processing circuit, communicatively coupled to the memory, wherein the instructions, when executed by the at least one processor individually or collectively, cause the wearable electronic device to: detect a state in which the wearable electronic device is worn on a wrist of a user using the sensor module, identify an activity state of the user using the sensor module based on detecting the state in which the wearable electronic device is worn on the wrist of the user, and adjust at least one of the angle between the housing structures and the bending curvature of the display based on a change in the activity state of the user.
Facts
- Company
- Samsung (Samsung Electronics Co., Ltd.)
- Official title
- WEARABLE ELECTRONIC DEVICE AND METHOD FOR OPERATING SAME
- Publication number
- US20260310256A1
- Application number
- 19676066
- Filed
- May 13, 2026
- Published
- Oct 8, 2026
- Inventors
- 2
- Claims
- 20
Classified under
G06F 1/163 Physics & computingG04G 21/025 Physics & computingG04G 21/08 Physics & computingG06F 1/165 Physics & computingG06F 1/1681 Physics & computingG06F 1/1692 Physics & computingMore from Samsung in Wearables
- Samsung patents wearable that tracks brain waves to suggest health actions Oct 6, 2026
- Samsung patents wristwatch with flexible screen that wraps around your wrist Oct 15, 2026
- Samsung patents ring that projects a screen onto your skin Oct 22, 2026
- Samsung patents glasses with moving lenses to adjust focus Sep 1, 2026
- Samsung patents wearable that adjusts walking force while you test walk Sep 8, 2026
Summaries are simplified from the filing’s own abstract and first claim. A patent filing is not a product announcement.
