Apple patents screen updates that avoid hidden sensor areas
Apple describes a method for updating the visual interface on a device screen to avoid specific areas where physical sensors are located. The system adjusts the layout of visual elements, such as status indicators or assistant feedback, to ensure they do not cover these hidden sensor zones.
In the filing’s own words
A computer system has a display area, wherein the display area at least partially encompasses a status region. The computer system detects a user input corresponding to the status region. In response to detecting the user input corresponding to the status region, the computer system, in accordance with a determination that the status region is associated with an active session of a respective application, performs an operation associated with the respective application and in accordance with a determination that the status region is not associated with an active session of a respective application, provides feedback associated with the user input without displaying information about a respective application in the status region and without performing an operation associated with a respective application.
What exactly they claim (claim 1)
1. A method, including: at a computer system that is in communication with one or more sensors and with a display generation component having a display area, wherein the one or more sensors are positioned within one or more sensor regions that are surrounded by the display area, the display generation component is not capable of displaying content within the one or more sensor regions, and a first display region of the display area encompasses the one or more sensor regions: detecting a user input invoking a virtual assistant of the computer system; in response to detecting the user input invoking the virtual assistant: displaying, in the first display region, a visual indication that the virtual assistant is active; receiving a voice command directed to the virtual assistant; and in response to receiving the voice command directed to the virtual assistant: performing, at the computer system, an operation responsive to the voice command; and updating the first display region, including displaying an outcome of the operation performed in response to the voice command, wherein the updating includes displaying visual elements that are selected so as to avoid overlapping locations of the one or more sensors in the first display region.
Facts
- Company
- Apple (Apple Inc.)
- Official title
- Devices, Methods, and Graphical User Interfaces for Updating a Session Region
- Publication number
- US20260310328A1
- Application number
- 19710271
- Filed
- Jun 16, 2026
- Published
- Oct 8, 2026
- Inventors
- 1
- Claims
- 20
