Nvidia patents method to split neural networks across processors
Nvidia describes a technique where a compiler automatically divides a neural network into smaller sections. These sections are then assigned to different processors to run at the same time, using data about the size of inputs and outputs to make the split.
In the filing’s own words
Apparatuses, systems, and techniques are presented schedule operations to be performed. In at least one embodiment, two or more data partitions of a neural network are caused to be automatically scheduled to be performed by two or more corresponding logical processors in parallel.
What exactly they claim (claim 1)
1. A processor, comprising: one or more circuits to: generate, as part of a first stage of a compiler, an intermediate representation of code to perform a neural network, the intermediate representation comprising one or more values indicating respective shape information of input values or output values of one or more intermediate computations; select two or more data partitions for the neural network to schedule performance by two or more processors in parallel, based, at least in part on the one or more values of the intermediate representation; and complete, as part of one or more second stages of the compiler, a schedule to perform the neural network by the two or more processors in parallel according to the selected two or more data partitions.
Facts
- Company
- Nvidia (Nvidia Corporation)
- Official title
- Automated partitioning for one or more neural networks
- Patent number
- US12754769B1
- Application number
- 17957540
- Filed
- Sep 30, 2022
- Granted
- Oct 6, 2026
- Inventors
- 3
- Claims
- 30
Classified under
