Apple patents system that guides users to switch between voice and touch inputs
This patent describes a method for electronic devices to recognize when a user is using one type of input, such as voice, and determine if a different input, like touch, would be better for the next step. If so, the device highlights specific areas on the screen to show the user where to tap to continue the task.
In the filing’s own words
Systems and processes for operating an intelligent automated assistant to perform intelligent list reading are provided. In accordance with one example, a method includes, at an electronic device having one or more processors, receiving a first user input of a first input type, the first user input including a plurality of words; displaying, on the touch-sensitive display, the plurality of words; receiving a second user input of a second input type indicating a selection of a word of the plurality of words, the second input type different than the first input type; receiving a third user input; modifying the selected word based on the third user input to provide a modified one or more words; and displaying, on the touch-sensitive display, the modified one or more words.
What exactly they claim (claim 1)
1. An electronic device, comprising: one or more processors; a memory; and one or more programs, wherein the one or more programs are stored in the memory and configured to be executed by the one or more processors, the one or more programs including instructions for: receiving a user input of a first input type, the user input indicative of a task; performing the task in response to the user input; determining whether the task may be performed in response to a user input of a second input type; in accordance with a determination that the task may be performed in response to a user input of a second input type: providing an output indicative of the user input of the second input type; and in accordance with a determination that the second input type includes a touch input type, highlighting one or more portions of a display of the electronic device to indicate to a user where on the display to provide the user input of the second input type.
Facts
- Company
- Apple (Apple Inc.)
- Official title
- Multi-modal interfaces
- Patent number
- US12748568B2
- Application number
- 18653896
- Filed
- May 2, 2024
- Granted
- Sep 29, 2026
- Inventors
- 4
- Claims
- 24
Classified under
G06F 3/167 Physics & computingG06F 3/04817 Physics & computingG06F 3/0482 Physics & computingG06F 3/0488 Physics & computingG06F 2203/0381 Physics & computingG10L 15/26 Physics & computingMore from Apple in AI & software
